Product Description

WIFI Mini household ip camera hd 720p 1.0 megapixel for home security surveillance system pan tile p2p wireless ip camera

Model No.:VG-1MP-772W

1.H.264 compression format, MJPEG/JPEG Baseline

2.Megapixel Resolution,Support 720P(1280*720)

3.Dual Stream, resolution, bit rate adjustable

4.Support Pan/Tilt control (Pan:355& Tilt:120) ,9/s Cruise

5.Freely control Pan/Tilt angle by software(PC or Smart Phone)

6.TF2.0 standard, maximum storage 32G

7.Support IR Cut , auto-switch day and night

8.Support two-way audio function

9.Motion detection recording , alert with snapshots via email (without SSL)

10.Build-in Privacy Mask , image snapshot , Title OSD , Alarm recordin , DDNS

11.Wi-Fi compliant with wireless standards IEEE 802.11b/g/n

12.Onvif Compliant, Support NVR from Milestone/Axxon/NUUO/geovision/synology/Hikvision/Dahua/Kodak

13.Support IE6.0~8.0, Firefox, Google chrome browser

14.Support iPhone/iPad/Android Smart Phone

15.Free CMS Software, paid Software for optional

Sensor		1/4" Progressive Scan CMOS OV9712
Effective Pixels		1280(H)720(V)
Min.Illumination		0.3lux(color) , 0.1lux(B/W IR On)
Day/Night		Auto,dual IR-Cut filter
IR LED		12pcs 5 IR Led, IR Range 10m
Max S/N Ratio		39dB
Electronic Shutter		Rolling Shutter
Interfaces
Optical lens	Interface	MTV interface
	Lens	Fixed Iris, Manual Focus
	Focal Length	Fixed Focal, 3.6mm / F1.4
	H View Angle	62.2
Audio Talkback		1 channel power MIC input, External access, AV interface
Audio Output		1 channel power speaker output, AV interface
Storage Interface		Micro TF Card supports video storage and image snapping;
		Included TF Card slot, upto 32G
I/O Alarm		-
Audio video encoding
Video Compression		H.264 Main Profile; MJPEG/JPEG Baseline
Resolution	Main Stream	HD 720P (1280*720) 25fps
	Sub Stream	(640360) / (352192) 25fps
Video Bitrate		32Kbps4Mbps,Supports CBR/VBR
Title OSD		Supports channel name, date, and video stream information overlay;
		OSD location is adjustable
Privacy Mask		4 configurable regions
Image Orientation		image flip and mirror
Auto Image Control Functions		Auto Exposure Control (AEC); Auto White Balance (AWB); Auto Band Filter (ABF)
		Auto Black Level Calibration (ABLC)
Image Controls		Color saturation, hue, gamma, sharpness (edge enhancement), lens correction,
		defective pixel canceling, and noise canceling
Audio Compression		G.711
Two Way Audio		Support
Data transmission and storage
Data storage		Video and Image
Recording		Recording set up to record by motion trigger,alarm trigger, manual, or schedule
Alarm Output		E-mail, Explorer, Software
Network protocol		TCP/IP , UDP , RTP , RTSP , RTCP , HTTP , DNS , DDNS , DHCP , FTP , NTP , PPPOE , SMTP , UPNP
Wireless protocols(-W)		802.11b/g/n, 150Mbps, Supports WEP,WPA,WPA2
ONVIF protocols		Support 2.0 version
Remote View	PC	IE 6.0~8.0 , Firefox , Chrome ;max 10 users
	Mobile Phone	iPhone, ipad, Android
General Parameters
Environmental Casing		Plastic material Housing, Indoor Use
Installation		Brackets Included, Wall Mount
Operating Temperature		-20 C ~ 50 C (-4 F ~ 122 F) for DC 12V
Operating Humidity		0% -85% RH
Power		DC5V
Power Consumption		9 W(MAX)
Dimension		125 mm (L) * 110mm(W) * 102mm(H)
Weight		0.36 Kg (0.79 bl)
Package Dimension		170mm170mm185mm
Package Weight		0.66 Kg (1.45 bl)
Approvals		CE FCC RoHS
