1.3 Megapixel H.264 network home security IR day&night mini indoor outdoor WIFI IP Camera

Product Details:

Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Product Description

1.3 Megapixel H.264 network home security IR day&night mini indoor outdoor WIFI IP Camera

Model No.:VG-IP930W

Main Features:

1.1/4" Progressive Scan CMOS V9712

2.H.264 & MJPEG dual-stream encoding

3.Max 25/30fps@720P(1280720)

4.Day/Night(ICR), 2DNR, AWB, AGC, BLC

5.Multiple network monitoring: Web viewer, CMS

6.6 mm lens

7.Max. IR LEDs length 10m

Technology Data:

Image Sensor		1/4" Progressive Scan CMOS OV9712
Effective Pixels		1280(H)x720(V)
Scanning System		Progressive
Electronic Shutter Speed		Auto/Manual, 1/3~1/10000s
Min. Illumination		Color: 0. 1Lux, B/W: 0.01Lux ; 0Lux(IR on)
S/N Ratio		>50dB
Camera Features
Max. IR LEDs Length		5 35pcs IR Led , IR Range 15m
Day/Night		Auto(ICR) / Color / B/W
Backlight Compensation		BLC
White Balance		Auto
Gain Control		Auto/Manual
Noise Reduction		2D
Privacy Masking		N/A
Lens
Focal Length		6mm
Max Aperture		F1.6
Angle of View		39.8
Mount Type		MTV mount (Interchangeable Lens)
Video
Compression		H.264 / MJPEG
Frame Rate	Main Stream	HD 720P (1280*720) 25fps
	Sub Stream	VGA 640*360 25FPS
Bit Rate		32-4096Kbps,Supports CBR/VBR
Network
Ethernet		RJ-45 (10/100Base-T)
Protocol		TCP/IP , UDP , RTP , RTSP , RTCP , HTTP , DNS , DDNS , DHCP , NTP , PPPOE , SMTP , UPNP
ONVIF		ONVIF Ver. 2.0
Max. User Access		10 users
Smart Phone		iPhone, iPad, Android
Wireless protocols(-W)		802.11b/g/n, 150Mbps, Supports WEP,WPA,WPA2
Auxiliary Interface
Memory Slot		N/A
General
Power Supply		DC12V
Power Consumption		<6W
Working Environment		-10C~+60C, 10%~90%
Ingress Protection		IP66
Dimension		165 mm (L) * 60 mm (W) * 60mm (H)
Weight		0.42 KG
Package Dimension		190 * 145 * 100mm
Package Weight		0.75KG
