POE IK10 Vandal proof 2.0 Megapixel IP Camera

Get a Price/Quote

Product Details:

Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Product Description

POE IK10 Vandal proof 2.0 Megapixel IP Camera

Main Features:

1/2.5 2.0 Mp Aptina CMOS
2.0 Megapxiel CMOS Sensor
1080P/720P(1~25fps/30fps)
Fixed lens 3.6/6mm /F1.2
Come with POE
IP66 & IK10 housing

Technology Data

Model	VG-D2.0MP-D5
Main Processor	Ti DaVinci Series DSP
Operating System	Embedded LINUX
Capacity	Simultaneous remote monitoring, local recording and remote control
User Interface	WEB, CMS, NVR
Camera
Image Sensor	1/2.5 2.0 Megapixel Progressive Scan Aptina CMOS sensor
Effective Pixels	1920(H)1080(V)
Electronic Shutter	1/5s to 1/50,000s
Mini. Illumination	Color:0.6Lux/F1.2 B/W:0.08Lux/F1.20Lux/F1.2(IR on)
Signal Noise Ratio	>50dB
Gain Control	Auto/Manual
White Balance	Auto/Manual
WDR Dynamic Range	DWDR
Lens Mount	M12
Lens	3.6mm Fixed Lens (6mm optional)F1.2
Video
Video Compression	H.264/MJPEG Optional
H.264 Encode Type	H.264 Baseline/H.264 Main Profile/H.264 High Profile Optional
Video Bit Rate	Main Stream500Kbps~12Mbps
Video Bit Rate	Sub Stream100Kbps~6Mbps
Image Resolution	1080P(19201080) / 720P(1280720) / D1(704576/704480)
Encoding Speed	Main Stream: 1080P/720P(1~25fps/30fps)
Encoding Speed	Extra Stream: D1/CIF(1~25fps/30fps)
Video Format	PAL/NTSC
Network
Ethernet	RJ-45 (10/100Base-T)
Network Protocol	IPv4/IPv6RTSP/RTP/RTCPTCP/UDPHTTPDHCPDNSFTPDDNSPPPoESMTP
Common Features	One button Reset, Prevent Flicker, Dual-stream, Heartbeat, Password Protect, Video cover, Motion Alarm
ONVIF	0NVIF Ver.2.3
Max User Access	10 users
Smart phone	Iphone , Ipad ,Android
Remote Operation	Monitor, Playback, System setting, File download, Log information, Maintenance & Upgrade
Auxiliary Interface
Reset Input	One Reset Button(Be effective after continues to hold down for 3 seconds)
Memory Slot	TF Card, Max 32GB
Environmental
Power Supply	DC12V
Power Consumption	<2.5W
Working Environment	-40C ~ +60C, Humidity less than95%(Non-condensing)
Protection Level	IP66
Dimensions(mm)	119.8mm x 67.5 x62mm
Weight(kg)	0.4kg
POE	IEEE802.3af
