Motor Control Trainer

FEATURES:

• 52060 is a versatile & most comprehensive setup to perform unique and hand-on training experiments in Motor Control Training.- Setup a Stepper Motors Driver. - Utilize a Stepper Motor for Positioning Control.
• Unique, First-in-Class, Micro controller & / or PC based experiment techniques. - Stepper Motors speed control. - Encoders application in stepper motor control.
• Onboard AT89C51RC micro controller with 32K bytes of Rom & 512 Bytes RAM. - Utilize a Potentiometer module for stepper motors Positioning Control.
• Onboard Uni-polar stepper Motor, Bipolar Stepper Motor, Servo Motor & DC Motor. -  Utilize an encoder to design a CLC.
• Onboard RED LEDs for Motor phase Indication, Direction and Mode Indications. - Forward, Reverse, Position Control. - Pulse Frequency, Pull-in Torque Characteristic.
• 16x2 LCD Display & 4x4 matrix keypad to display & control parameters in local mode operations. - Self Starting & Accelerating -Decelerating Zone.- Encoder in the stepper motor CLC.
• Three Modes of operation : MCU, PC, Stand Alone. - Potentiometer in stepper motors control.
• SPDT Switch is used for in Stand Alone Mode; - Step Counting on particular Modes. - Mode selection (HALF, FULL and WAVE), - Angle Measurement on Particular modes - Speed Controlling, and - DC Motor Speed & Direction Control. - STEP & RUN Mode Selection. - Servo Motor Angle Selection.
• On board Auto & Manual Clock available.
• Supplied in attractive Wooden enclosure.
• On board Rs232 Serial Communication.
• Documentation includes User Manual with details.
• On board Jack for use with 5V adapter.
• Cable & connector set available for interfacing.
• Part List of Experiments
