Sensor Trainer Board

Product Description

Sensor Trainer Board (ITI)

52085 is a Sensor Trainer offer Complete training opportunity for most commonly used Sensor available for experimenting in the Laboratory. Due to the typical Strength obtain from a sensor is not enough to process the signal; this board provides signal conditioners with Digital panel meter for display.

Specifications:

• On-board Digital Panel Meter provided
• Measuring range of +/-1V
• Input available on 2mm Banana sockets

RPM Meter:

• Digital RPM Meter
• Input available on 2mm Banana sockets

LVDT Transducer:

• LVDTTransducer with transparent enclosure.
• Displacement of ± 5mm
• Primary Excitation voltage of Sine wave 1V p-p.
• Signal Conditioning Amplifier
• LVDT transparent With Screw Gauge unit

Strain / Load Cell Transducer:

• Resistive Load cell is used.
• Load/Strain in weights can be measured up to 3 Kgs.
• Primary Excitation voltage of 12V DC
• Signal Conditioning Amplifier
• Cantilever Load Cell platform Unit for Strain & Load Cell Setup
• Weight unit up to 3Kgs

Temperature Sensor:

• K-type Thermocouple is used.
• PT-100 Type RTD sensor is used
• LM335 Sensor.
• Thermistor Sensor

Signal Conditioning Amplifier:

• Heater, Thermometer, Transparent Jar unit for Temperature setup

Speed Sensor:

• Proximity Switch is used for Magnetic Pickup.
• DC Motor with Proximity Switch for Speed Measurement Setup

Smoke Sensor:

• MQ2 Smoke Sensor.
• Buzzer for Alarm

Signal Conditioning & Amplifier:

• Instrumentation amplifier
• All interconnections are made using 2mm socket.
• Test points are provided to analyze signals at various points.
• All ICS are mounted on IC Sockets.
• Bare board Tested Glass Epoxy SMOBC PCB is used.
• In-Built Power Supply of ±5V, ±12V.
• Attractive Metal Enclosure
• User Manual for Experiments.
