Measurement and Control Of Temperature Using RTD Transducer
12000 INR
Product Details:
- Material Plastic
- Dimensions 425 x 102 x 38 Millimeter (mm)
- Shape Rectangle
- Color Black and Blue
- Click to View more
X
Measurement and Control Of Temperature Using RTD Transducer Price And Quantity
- 12000 INR
- 1 Piece
Measurement and Control Of Temperature Using RTD Transducer Product Specifications
- 425 x 102 x 38 Millimeter (mm)
- Black and Blue
- Plastic
- Rectangle
Measurement and Control Of Temperature Using RTD Transducer Trade Information
- Telegraphic Transfer (T/T)
- 100 Piece Per Month
- 4-5 Week
- Yes
- Sample costs shipping and taxes has to be paid by the buyer
- Australia, Eastern Europe, Middle East, Africa, South America, Western Europe, Asia, Central America, North America
Product Description
Measurement and Control Of Temperature Using RTD Transducer
Industrial Control Transducer has been designed specifically for measurement and control of temperature using RTD Transducer. The board require other apparatus like heater and beaker.
Practical experience on this set up carries great educative value for Science and Engineering Students.
Object:
Measurement and control of temperature using RTD transducer
Feature:
The unit consists of following built in parts :
- +12V DC at 100 mA, IC Regulated Power Supply
- 6 V DC at 100 mA, IC Regulated Power Supply
- Four Op-Amp. ICs
- Relay 12 V DC, one change over
- One NPN transistor
- 31/2 digits display panel meter, to display temperature in oC
- RTD sensor with 3 pin connector
- One switch for setting temperature on one side and to read actual temperature on other side
- Potentiometer to control temperature
- AC mains socket to connect load whose temperature is to be controlled
- Adequate no. of other Electronic Components
- Mains ON/OFF Switch and Fuse 400 mA
- The unit is operative on 230V +10% at 50Hz AC Mains
- Good Quality, reliable terminal/sockets are provided at appropriate places on panel for connections/ observation of waveforms
- Strongly supported by detailed Operating Instructions, giving details of Object Theory, Design, Procedures, Report Suggestions
- Weight : 4 Kg. (Approx)
- Dimension : W 412 x H 150 x D 310
Other Apparatus Required:
- Heater 1000 W 230V
- Beaker
